VEMAX is a manufacturer of equipment for the label, packaging, foil, tape, and tag market. We have been constantly improving our processes and designs in order to obtain market recognition regarding the quality and reliability of our products.
As proof of this evolution, we can highlight some characteristics that show we are on the right path, they are:
•38 years in the local and international market, always in tune with market needs, always innovating and pioneering the application of new technologies for slitter inspection rewinders.
•Flexibility in working with the most diverse and modern inspection systems on the market, such as: NIKKA, AVT, BST and E+L.
•All our equipment is CE certified and meets the most demanding safety standards.
•Innovative operating system, SIC Series. A unique system, with features such as control of user levels, recording of work recipes, automatic control of tension.
•We use the best components in the manufacture of our machines such as Siemens, Festo, Leuze, Pepper Fuchs, BST, RE Latina, E+L, Pulse Selectra, Unilux etc.
•Machines with ergonomic and compact designs. This reduces fatigue, which translates into increased productivity.
•Quick machine setup with input and output systems using pneumatic locking and pressure sensing roller devices.
•Proportional tension control system on rewinder and unwinder, enabling precise and uniform control on the webs.
•Maximum rewind speed *300m/min.
•Remote technical assistance (via Internet), reducing maintenance costs.
•Industry-standard, easy-to-purchase mechanical, electrical and electronic components.
•Extremely robust construction providing low maintenance costs in addition to extending the life of the equipment.
•High precision tension control, honed by over 3 decades of experience and know-how in the slitter rewinder category.
Volts 220/208 Phase 3 VAC 30AMP
MANUFACTURING SPECS
• Machine side frame made with SAE 1020 certified steel plates; oxy-slitting in a thickness
of 1” in. (25 mm), machined on a C.N.C. with drawings generated in C.A.M.
• Other parts machined on C.N.C. with SAE 1045 steel using heat and surface treatment
when necessary.
• SAE 1020 steel electrical and machine panels.
• All parts cleaned with phosphating treatment.
• High melting powder electrostatic painting (200º C) with high corrosion protection.
DRIVE CHARACTERISTICS
• Nip driven through CA motor, with 2HP WEG .
• Rewinders driven through CA motor, with 2HP WEG.
• Modular brake, with pneumatic actuation of 2 Vemax calipers for unwinder.
ELECTRONIC CHARACTERISTICS
• Motors controlled by frequency inverters using the latest generation.
• Easily accessible electrical panel with components protected by ultra-fast circuit breakers
and over tension relays.
• Electronic component operating manuals and complete electrical schematics for
maintenance provided.
NOT INCLUDED OPTIONAL ACCESSORIES
- INSPECTION SYSTEM SMARTSCAN 100% E+L (GERMAN)
- AXION CAMERA SYSTEM 100%
- Build out for inspection system in buffer
- PNEUMATIC WASTE ELIMINATION SYSTEM VRR
-VRRS FLAG SENSOR
-SECOND KNIFE ASSEMBLY w/ FIVE 5 RAZORS
-Quick change hubs PER SHAFT
-1 inch air shafts for use with Quick change Hubs
- 1.5 inch air shafts for use with Quick change Hubs
- 2.0 inch air shafts for use with Quick change Hubs
3" CORE DIAMETER ON UNWIND, 3" CORE DIAMETER ON REWINDS, STROBE FOR INSPECTION, 985 FEET PER MIN.
S.I.C. INTERGRADE CONTROL SYSTEM- COMMAND AND CONTROL PANEL
• Automatic tension control on unwinder and rewinder.
• Automatic acceleration and deceleration ramps
• Automatic stop by length or quantity of labels/tags or diameter in the unwinder
• Internal memory, allowing you to store job recipes, with quantity, length, tension, pitch, names, while
controlling users and production by product.
• Ergonomic vertical inspection position.
100% electronic edge aligner with splice table.
Unwinder with film lock through pneumatic push-pull valve on web guide
Unwinder using expansive shaft with ruler. 3-inch diameter cantilevered shaft.
Rewinder using CA motor, working in torque mode, with automatic tension control
Rewinder using expansive shaft with ruler. 3” in diameter cantilevered shaft. Optional other diameters
Knife slitting system, with 05 rotary knife blades.
Pneumatic film locks on rewinders to maintain the position of the slitting when changing cores.
Electrical panel with all components protected by ultra-fast circuit breakers and over tension relays.
Operating manuals, electrical and pneumatic diagram
Machine inspected and approved with NR12
